  11. Lug Compression Connector, 350 kcmil Max, Standard Barrel, Copper, Red
Panduit Lug Compression Connector, 350 kcmil Max, Standard Barrel, Copper, Red LCAN350-38-X - main

Lug Compression Connector, 350 kcmil Max, Standard Barrel, Copper, Red

  • Mfr # LCAN350-38-X

  • Zoro # G0773022

product price: $21.89
/ea

Key Features

Cable Size
350 kcmil
Connector Type
Standard Barrel
Width
0.88"
Material
Copper
Length
3"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAN350-38-X
Zoro #
G0773022
UPC #
7498360345
Country of Origin
Mexico

Dimensions

Cable Size
350 kcmil
Width
0.88"
Length
3"
Overall Length
3 in
Tongue Thickness (mm)
4.3
Copper Code Conductor Size (kcmil)
350
Barrel Length (mm)
36.6
Overall Length (mm)
76.2
Inside Diameter (In.)
0.88
Outer Diameter (In.)
0.88
Wire Strip Length (mm)
38.1
Barrel Length (In.)
1.44
Tongue Thickness (In.)
0.21
Stud Hole Size (In.)
44993
Tongue Width (In.)
0.88
Tongue Width (mm)
22.4
Inside Diameter (mm)
22.35
Outer Diameter (mm)
22.35
Wire Strip Length (In.)
37257
Stud Hole Size (mm)
9.5
Overall Length (In.)
3
For Wire Size
350 kcmil
Tongue Width
0.88 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Red
Item
Lug Compression Connector
Die Code
18
Standards
C22.2 No. 65-13, 486A-486B File #E52165
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, Angled Connector
Burndy Die Index Number
18
Lug Type
1 Stud Hole Lug
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
Straight
Base Material
Copper
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Panduit Die Index Number
P71
UL Temperature Rating (°C)
90
Tongue Type
Narrow
T & B Die Index Number
18
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,350 Kcmil
