  11. Lug Compression Connector, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple
Panduit Lug Compression Connector, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple LCAX4/0-12F-X - main

Lug Compression Connector, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-12F-X

  • Zoro # G0774002

product price: $19.45
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Standard Barrel
Width
1.19"
Material
Copper
Length
2.18"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-12F-X
Zoro #
G0774002
UPC #
7498343566
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
2.18"
Overall Length
2.18 in
Barrel Length (mm)
26.2
Copper Code Conductor Size (AWG)
36617
Class K Copper Flex Conductor Size (AWG)
36617
Tongue Thickness (In.)
0.16
Class M Copper Flex Conductor Size (AWG)
36617
Tongue Thickness (mm)
4.1
Class H Copper Flex Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Overall Length (In.)
2.18
DLO Copper Flex Conductor Size (AWG)
36617
Overall Length (mm)
55.4
Stud Hole Size (In.)
1 to 2
Class G Copper Flex Conductor Size (AWG)
36617
Barrel Length (In.)
1.03
Stud Hole Size (mm)
12.7
Wire Strip Length (In.)
1.0625
Tongue Width (mm)
30.2
Class I Copper Flex Conductor Size (AWG)
36617
Wire Strip Length (mm)
27
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.19 in
For Wire Size
4/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Purple
Item
Lug Compression Connector
Die Code
15
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
90° Angled Connector, Corrosion Resistant
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Base Material
Copper
Tongue Type
Standard
T & B Die Index Number
54
Burndy Die Index Number
15
Tongue Angle
90 Degrees Angled
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Panduit Die Index Number
P54
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
