  6. Lug Compression Connector, 4/0 AWG Max, Long Barrel, Copper, Purple
Panduit Lug Compression Connector, 4/0 AWG Max, Long Barrel, Copper, Purple LCB4/0-38-X - main

Lug Compression Connector, 4/0 AWG Max, Long Barrel, Copper, Purple

  • Mfr # LCB4/0-38-X

  • Zoro # G0774617

product price:  $12.99
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
1.06 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCB4/0-38-X
Zoro #
G0774617
UPC #
7498390139
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
Barrel Size
Long
Tongue Width
1.06 in
Cable Size
4/0 AWG
Length
3.03 in
Width
1.06 in
Overall Length
3.03 in
Barrel Length (mm)
39.6
Inside Diameter (mm)
14.47
Tongue Thickness (mm)
3.6
Tongue Width (mm)
26.9
Overall Length (In.)
3.03
Tongue Thickness (In.)
0.14
Barrel Length (In.)
1.56
Wire Strip Length (In.)
39452
Outer Diameter (In.)
0.71
Wire Strip Length (mm)
41.2
Inside Diameter (In.)
0.57
Tongue Width (In.)
1.06
Overall Length (mm)
77
Stud Hole Size (In.)
44993
Stud Hole Size (mm)
9.5
Copper Code Conductor Size (AWG)
36617
Outer Diameter (mm)
18.03

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
15
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Features
Corrosion Resistant, Angled Connector
Connection Material
Tin
Connection Type
1 x Terminal
Lug Type
1 Stud Hole Lug
Base Material
Copper
Tongue Type
Standard
Burndy Die Index Number
15
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Panduit Die Index Number
P54
Product Type
Copper Compression Connectors - Lugs
T & B Die Index Number
15
UL Temperature Rating (°C)
90
Product Material
Copper
Connector Plating
Tin
Product Name
Terminal Connector
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,4/0 AWG
