  11. Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-56-X - main

Lug Compression Connector, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-56-X

  • Zoro # G0774081

product price: $13.89
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Standard Barrel
Width
1.19"
Material
Copper
Length
2.53"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-56-X
Zoro #
G0774081
UPC #
7498343557
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
2.53"
Overall Length
2.53 in
Wire Strip Length (In.)
42370
Class H Copper Flex Conductor Size (AWG)
36617
Class M Copper Flex Conductor Size (AWG)
36617
Wire Strip Length (mm)
26.9
Barrel Length (mm)
26.2
Overall Length (mm)
64.3
Inside Diameter (In.)
0.65
Class G Copper Flex Conductor Size (AWG)
36617
Stud Hole Size (In.)
45062
Outer Diameter (mm)
20.57
DLO Copper Flex Conductor Size (AWG)
36617
Class K Copper Flex Conductor Size (AWG)
36617
Inside Diameter (mm)
16.51
Overall Length (In.)
2.53
Tongue Thickness (mm)
4.1
Class I Copper Flex Conductor Size (AWG)
36617
Outer Diameter (In.)
0.81
Tongue Thickness (In.)
0.16
Tongue Width (mm)
30.2
Barrel Length (In.)
1.03
Copper Code Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Stud Hole Size (mm)
7.9
Barrel Size
Standard
For Wire Size
4/0 AWG
Tongue Width
1.19 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Purple
Item
Lug Compression Connector
Die Code
15
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, Angled Connector
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
Straight
T & B Die Index Number
15
Lug Type
1 Stud Hole Lug
UL Temperature Rating (°C)
90
Panduit Die Index Number
P54
Finish/Coating
Tin-Plated
Tongue Type
Standard
Burndy Die Index Number
15
Base Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
