  6. Two-Hole Compression Lug, 650 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black
Panduit Two-Hole Compression Lug, 650 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black LCCX650-12-6 - main

Two-Hole Compression Lug, 650 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Black

  • Mfr # LCCX650-12-6

  • Zoro # G0777073

product price:  $93.99
/ea
Free Shipping & Returns

Key Features

For Wire Size
650 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCCX650-12-6
Zoro #
G0777073
UPC #
7498319824
Country of Origin
Mexico

Dimensions

For Wire Size
650 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.95 in
Width
1.95"
Cable Size
650 kcmil
Length
6-3/4"
Overall Length
6.75 in
Tongue Width (In.)
1.95
Stud Hole Size (In.)
1 to 2
Tongue Width (mm)
49.5
Tongue Thickness (In.)
0.3
DLO Copper Flex Conductor Size (kcmil)
646.4
Outer Diameter (In.)
1.35
Wire Strip Length (In.)
3
Tongue Thickness (mm)
7.6
Overall Length (mm)
171.5
Stud Hole Size (mm)
12.7
Barrel Length (mm)
74.7
Inside Diameter (mm)
26.67
Barrel Length (In.)
2.94
Overall Length (In.)
6.75
Wire Strip Length (mm)
76.2
Outer Diameter (mm)
34.29
Inside Diameter (In.)
1.05
Outside Diameter Inches
1.35 in

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
24
Color Code
Black
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
UL Temperature Rating (°C)
90
Panduit Die Index Number
P106
T & B Die Index Number
24
Tongue Type
Standard
Lug Type
2 Stud Hole Lug
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (mm)
44.5
Finish/Coating
Tin-Plated
Stud Hole Spacing (In.)
1.75
Burndy Die Index Number
24
Maximum Voltage (kV)
35
Connector Details
1 x Terminal
Connector Plating
Tin
Product Name
Terminal Connector
Product Material
Copper
Product Class
Wire Termination
Number of Holes
2

Description

Lug Compression Connector,650 Kcmil

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
