Shop PANDUIT

Lug Compression Connector, 500 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Pink

  • Mfr # LCAX500-12-6

  • Zoro # G0774230

product price:  $42.65
/ea

Key Features

For Wire Size
500 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX500-12-6
Zoro #
G0774230
UPC #
7498343603
Country of Origin
Mexico

Dimensions

For Wire Size
500 kcmil
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.89 in
Cable Size
500 kcmil
Length
3.64"
Width
1.89"
Overall Length
3.64 in
Overall Length (In.)
3.64
Outer Diameter (mm)
33.02
Stud Hole Size (In.)
1 to 2
Outer Diameter (In.)
1.3
Class M Copper Flex Conductor Size (kcmil)
500
Inside Diameter (mm)
26.16
Overall Length (mm)
92.5
Barrel Length (mm)
37.6
Stud Hole Size (mm)
12.7
Wire Strip Length (mm)
39.6
Inside Diameter (In.)
1.03
Class K Copper Flex Conductor Size (kcmil)
500
Barrel Length (In.)
1.48
Class H Copper Flex Conductor Size (kcmil)
500
Wire Strip Length (In.)
42378
Tongue Thickness (mm)
6.6
DLO Copper Flex Conductor Size (kcmil)
535.3
Tongue Thickness (In.)
0.26
Class I Copper Flex Conductor Size (kcmil)
500
Tongue Width (In.)
1.89
Tongue Width (mm)
48
Class G Copper Flex Conductor Size (kcmil)
500

Details

Item
Lug Compression Connector
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Color Code
Pink
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Angled Connector, Corrosion Resistant
Finish/Coating
Tin-Plated
Product Type
Copper Compression Connectors - Lugs
Base Material
Copper
Burndy Die Index Number
L99
UL Temperature Rating (°C)
90
Lug Type
1 Stud Hole Lug
T & B Die Index Number
L99
Panduit Die Index Number
P99
Maximum Voltage (kV)
35
Tongue Type
Standard
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Wire Termination

Description

Lug Compression Connector,500 Kcmil

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
