  11. One-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray
Panduit One-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray LCB4-38-L - main

One-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray

  • Mfr # LCB4-38-L

  • Zoro # G0774772

product price: $4.59
/ea
Sold in multiples of 2 for $9.18

Key Features

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Connector Type
Long Barrel
Width
0.62"
Material
Copper
Length
2.17"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCB4-38-L
Zoro #
G0774772
UPC #
7498343275
Country of Origin
Mexico

Dimensions

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Width
0.62"
Length
2.17"
Overall Length
2.17 in
Overall Length (In.)
2.17
Wire Strip Length (mm)
28.6
Tongue Width (mm)
15.7
Barrel Length (mm)
26.7
Barrel Length (In.)
1.05
Tongue Thickness (In.)
0.07
Stud Hole Size (mm)
9.5
Maximum Wire Size (AWG)
35
Tongue Thickness (mm)
1.8
Tongue Width (In.)
0.62
Overall Length (mm)
55.1
Wire Strip Length (In.)
1.13
Stud Hole Size (In.)
44993
Copper Code Conductor Size (AWG)
4
Tongue Width
0.62 in
For Wire Size
4 to 2 AWG
Barrel Size
Long

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Gray
Item
One-Hole Compression Lug
Die Code
8
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Features
Corrosion Resistant, Angled Connector
Connection Material
Tin
Connection Type
1 x Terminal
Product Type
Copper Compression Connectors - Lugs
Tongue Type
Standard
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Burndy Die Index Number
8
Panduit Die Index Number
P29
Tongue Angle
Straight
Base Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,4-3 AWG

Restrictions
