  6. Lug Compression Connector, No.8 AWG

This item is Discontinued.

Panduit Lug Compression Connector, No.8 AWG LCB8-38-L

Lug Compression Connector, No.8 AWG (Discontinued)

  • Mfr # LCB8-38-L
  • Zoro # G0775070
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCB8-38-L
Zoro #
G0775070
UPC #
7498343277
Country of Origin
Mexico

Dimensions

Cable Size
8 AWG
Width
0.6"
Length
1-3/4"
Overall Length
1.75 in
Wire Strip Length (mm)
19.1
Barrel Length (In.)
0.7
Overall Length (In.)
1.75
Tongue Thickness (In.)
0.05
Overall Length (mm)
44.5
Stud Hole Size (In.)
44993
Stud Hole Size (mm)
9.5
Tongue Width (mm)
15.2
Barrel Length (mm)
17.8
Tongue Width (In.)
0.6
Tongue Thickness (mm)
1.3
Copper Code Conductor Size (AWG)
8

Details

Connector Type
Long Barrel
Material
Tin-Plated Copper
Color Code
Red
Item
Lug Compression Connector
Features
Angled Connector, Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
Finish/Coating
Tin-Plated
Burndy Die Index Number
49
Base Material
Copper
UL Temperature Rating (°C)
90
Tongue Angle
Straight
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Barrel Type
Long Barrel Length without Inspection Window
Standards Met
C22.2 No. 65-13, 486A-486B File #E52164
Maximum Voltage (kV)
35
Panduit Die Index Number
P21
Connector Plating
Tin
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,No.8 AWG
