Shop PANDUIT

Male Disconnect, Nylon, 22-18AWG, PK1000

  • Mfr # DPF18-250FIM-M

  • Zoro # G0765952

product price:  $493.99
/pk 1000, $0.49/ea
Free Shipping & Returns

Key Features

For Use With
CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
Color Code
Red
Insulation Type
Fully Insulated
Overall Length
0.9 in
Features
Flame Retardant, Strain Relief
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
DPF18-250FIM-M
Zoro #
G0765952
UPC #
7498320339
Country of Origin
Mexico

Dimensions

Overall Length
0.9 in
Width
0.4"
Height
0.29 in
Overall Width (In.)
0.41
Wire Strip Length (In.)
11933
Overall Width (mm)
10.4
Overall Height (In.)
0.29
Maximum Wire Insulation Diameter (In.)
0.13
Overall Length (In.)
0.9
Wire Strip Length (mm)
7.1
Maximum Copper Conductor Size (AWG)
#18
Overall Height (mm)
7.4
Tab Size (mm)
6.3 x 0.8
Tab Size (In.)
0.250 x 0.032
Maximum Wire Insulation Diameter (mm)
3.38
Maximum Wire Size (AWG)
#18
Minimum Metric Conductor Size (mm²)
0.5
Overall Length (mm)
22.9
Minimum Wire Size (AWG)
#22
Maximum Metric Conductor Size (mm²)
1

Details

Item
Male Disconnect,Nylon,22-18AWG,PK1000
For Use With
CT-1525, CT-2300/ST (CD-525), CT-2500/L (CT-2525CH), UP14ZLW (CD-525)
Color Code
Red
Insulation Type
Fully Insulated
Features
Flame Retardant, Strain Relief
Disconnect Type
Male Tab Disconnect
Maximum Operating Temperature (°C)
105
Tongue Angle
Straight
Barrel Type
Funnel
Maximum Operating Temperature (°F)
221
Flammability Rating
UL94V-2/UL94-HB
Insulation Material
Premium Nylon
Product Type
Disconnect
Maximum Voltage (kV)
0.6
Base Material
Brass
Finish/Coating
Nickel-Plated
Standards Met
UL 310, CSA 22.2 No.153
Maximum Voltage (V)
600
Product Line
DiscoGrip
Contact Plating
Nickel
Product Material
Brass
Product Name
DiscoGrip Terminal Connector
Connector Details
1 x Quick Disconnect
Product Color
Red
Max Operating Temperature
105 degrees celsius
Product Class
Wire Termination

Description

Male Disconnect,Nylon,22-18AWG,PK1000, Package Quantity 1000

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
