Panduit Male Disconnect, premium nylon fully ins DPF18-250FIMB-K

Male Disconnect, premium nylon fully ins (Discontinued)

  • Mfr # DPF18-250FIMB-K
  • Zoro # G3036296
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
DPF18-250FIMB-K
Zoro #
G3036296
UPC #
7498320642
Country of Origin
Mexico

Dimensions

Overall Length
0.92 in
Height
0.34 in
Width
0.5"
Insulation Diameter (In.)
0.13
Minimum Copper Conductor Size (AWG)
#22
Maximum Wire Insulation Diameter (mm)
3.4
Minimum Metric Conductor Size (mm²)
0.5
Overall Width (In.)
0.46
Overall Length (mm)
23.4
Overall Length (In.)
0.92
Tab Size (mm)
6.3 x 0.8
Maximum Copper Conductor Size (AWG)
#18
Wire Strip Length (mm)
7.1
Insulation Diameter (mm)
3.4
Overall Width (mm)
11.7
Minimum Wire Size (AWG)
#22
Maximum Wire Insulation Diameter (In.)
0.13
Maximum Metric Conductor Size (mm²)
1
Wire Strip Length (In.)
11933
Tab Size (In.)
0.250 x 0.032
Maximum Wire Size (AWG)
#18

Details

For Use With
Crimp press with CA9 (CD9-10B) or CA-800EZ (CD-800-10) applicator
Color Code
Red
Insulation Type
Fully Insulated
Features
Flame Retardant, Molded, Strain Relief
Maximum Operating Temperature (°F)
221
Disconnect Type
Male Tab Disconnect
Flammability Rating
UL94V-2/UL94-HB
Tongue Angle
Straight
Insulation Material
Premium Nylon
Product Type
Disconnect
Maximum Voltage (kV)
0.6
Maximum Voltage (V)
600
Standards Met
UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
Barrel Type
Funnel
Seam Type
Butted
Finish/Coating
Nickel-Plated
Base Material
Brass
Maximum Operating Temperature (°C)
105
Contact Plating
Nickel
Product Color
Red
Connector Details
1 x Quick Disconnect
Product Material
Brass
Product Name
Terminal Connector
Product Class
Wire Termination
Max Operating Temperature
105 degrees celsius

Description

Male Disconnect, premium nylon fully insulated, oversized housing, 12 - 18 AWG, .250 x .032 tab size, funnel entry
