  11. One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green
Panduit One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green LCD1-14A-E - main

One-Hole Compression Lug, 1 AWG Max, Standard Barrel, Copper, Green

  • Mfr # LCD1-14A-E

  • Zoro # G0777143

product price: $10.95
/ea

Key Features

Cable Size
1 AWG
Connector Type
Standard Barrel
Width
0.7"
Material
Copper
Length
2.42"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD1-14A-E
Zoro #
G0777143
UPC #
7498338293
Country of Origin
Mexico

Dimensions

Cable Size
1 AWG
Width
0.7"
Length
2.42"
Overall Length
2.42 in
Copper Code Conductor Size (AWG)
1
Wire Strip Length (mm)
23.8
Overall Length (mm)
61.5
Barrel Length (mm)
22.4
Tongue Thickness (mm)
2.8
Barrel Length (In.)
0.88
Wire Strip Length (In.)
15/16
Tongue Thickness (In.)
0.11
Overall Length (In.)
2.42
Stud Hole Size (In.)
44930
Tongue Width (mm)
17.8
Tongue Width (In.)
0.7
Stud Hole Size (mm)
6.4
For Wire Size
1 AWG
Tongue Width
0.70 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Green
Item
One-Hole Compression Lug
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Die Code
11
Features
Corrosion Resistant
UL Temperature Rating (°C)
90
T & B Die Index Number
37
Stud Hole Spacing (In.)
0.63
Burndy Die Index Number
11
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Stud Hole Spacing (mm)
16
Panduit Die Index Number
P37
Maximum Voltage (kV)
35
Tongue Angle
Straight
Base Material
Copper
Tongue Type
Standard
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Name
Terminal Connector
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.1 AWG
