  11. One-Hole Compression Lug, 1/0 AWG Max, Long Barrel, Copper, Pink
Panduit One-Hole Compression Lug, 1/0 AWG Max, Long Barrel, Copper, Pink LCBX1/0-38-X - main

One-Hole Compression Lug, 1/0 AWG Max, Long Barrel, Copper, Pink

  • Mfr # LCBX1/0-38-X

  • Zoro # G0421292

product price: $9.44
/ea

Key Features

For Wire Size
1/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
0.85 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCBX1/0-38-X
Zoro #
G0421292
UPC #
7498343685
Country of Origin
Mexico

Dimensions

For Wire Size
1/0 AWG
Barrel Size
Long
Tongue Width
0.85 in
Cable Size
1/0 AWG
Width
0.85"
Length
2.67"
Overall Length
2.67 in
Class H Copper Flex Conductor Size (AWG)
36526
Barrel Length (In.)
1.5
Overall Length (In.)
2.67
Tongue Width (mm)
21.6
Tongue Thickness (mm)
3.3
DLO Copper Flex Conductor Size (AWG)
36526
Class K Copper Flex Conductor Size (AWG)
36526
Class G Copper Flex Conductor Size (AWG)
36526
Stud Hole Size (mm)
9.5
Tongue Thickness (In.)
0.13
Class I Copper Flex Conductor Size (AWG)
36526
Stud Hole Size (In.)
44993
Barrel Length (mm)
38.1
Copper Code Conductor Size (AWG)
36526
Wire Strip Length (mm)
40
Overall Length (mm)
67.8
Tongue Width (In.)
0.85
Class M Copper Flex Conductor Size (AWG)
36526

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
12
Color Code
Pink
Connector Type
Long Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Angled Connector, Corrosion Resistant
Panduit Die Index Number
P42
Burndy Die Index Number
12
Base Material
Copper
Tongue Type
Standard
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Wire Termination

Description

Lgflex Lug,1/0 Awg,.38 In. Stud,Wdw
