  11. One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink
Panduit One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink LCA1/0-38H-X - main

One-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink

  • Mfr # LCA1/0-38H-X

  • Zoro # G0771290

product price: $9.79
/ea

Key Features

Cable Size
1/0 AWG
Connector Type
Standard Barrel
Width
0.76"
Material
Copper
Length
1.76"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA1/0-38H-X
Zoro #
G0771290
UPC #
7498355848
Country of Origin
Mexico

Dimensions

Cable Size
1/0 AWG
Width
0.76"
Length
1.76"
Overall Length
1.76 in
Stud Hole Size (In.)
44993
Tongue Thickness (In.)
0.12
Barrel Length (In.)
0.94
Wire Strip Length (mm)
25.4
Tongue Width (In.)
0.76
Overall Length (mm)
44.7
Overall Length (In.)
1.76
Tongue Width (mm)
19.3
Stud Hole Size (mm)
9.5
Copper Code Conductor Size (AWG)
36526
Tongue Thickness (mm)
3
Barrel Length (mm)
23.9
Wire Strip Length (In.)
1
Barrel Size
Standard
For Wire Size
1/0 AWG
Tongue Width
0.76 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Pink
Item
One-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connection Material
Tin
Connection Type
1 x Terminal
Features
45° Angled Connector, Corrosion Resistant
Tongue Angle
45 Degrees Angled
UL Temperature Rating (°C)
90
Tongue Type
Standard
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
Base Material
Aluminum
Panduit Die Index Number
P42
Burndy Die Index Number
12
Finish/Coating
Tin-Plated
Connector Plating
Tin
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Material
Copper
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,1/0 AWG
