  11. One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black LCAX2/0-12F-X - main

One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCAX2/0-12F-X

  • Zoro # G0773792

product price: $13.99
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.96"
Material
Copper
Length
1.98"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX2/0-12F-X
Zoro #
G0773792
UPC #
7498343544
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.96"
Length
1.98"
Overall Length
1.98 in
Overall Length (In.)
1.98
Barrel Length (In.)
0.83
Stud Hole Size (In.)
1 to 2
Copper Code Conductor Size (AWG)
36557
Tongue Width (mm)
24.4
Tongue Thickness (In.)
0.13
Barrel Length (mm)
21.1
Overall Length (mm)
50.3
Tongue Width (In.)
0.96
Wire Strip Length (mm)
22.2
Stud Hole Size (mm)
12.7
Tongue Thickness (mm)
3.3
Tongue Width
0.96 in
For Stud Size
1 to 2 in
Barrel Size
Standard
For Wire Size
2/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
One-Hole Compression Lug
Die Code
13
Connection Material
Tin
Connection Type
1 x Terminal
Features
90° Angled Connector, Corrosion Resistant
Tongue Angle
90 Degrees Angled
UL Temperature Rating (°C)
90
Tongue Type
Standard
Maximum Voltage (kV)
35
Panduit Die Index Number
P45
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Burndy Die Index Number
13
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
