  6. One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black LCA2/0-38H-X - main

One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black

  • Mfr # LCA2/0-38H-X

  • Zoro # G0771543

product price:  $11.99
/ea

Key Features

For Wire Size
2/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.85 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCA2/0-38H-X
Zoro #
G0771543
UPC #
7498355853
Country of Origin
Mexico

Dimensions

For Wire Size
2/0 AWG
Barrel Size
Standard
Tongue Width
0.85 in
Cable Size
2/0 AWG
Length
1.83"
Width
0.85"
Overall Length
1.83 in
Tongue Width (In.)
0.85
Overall Length (mm)
46.5
Tongue Width (mm)
21.6
Barrel Length (In.)
0.98
Tongue Thickness (mm)
3.3
Stud Hole Size (mm)
9.5
Stud Hole Size (In.)
44993
Overall Length (In.)
1.83
Tongue Thickness (In.)
0.13
Wire Strip Length (mm)
27
Barrel Length (mm)
24.9
Copper Code Conductor Size (AWG)
36557
Wire Strip Length (In.)
1.06

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
45 Degrees Angled
Die Code
13
Color Code
Black
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, 45° Angled Connector
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
13
Maximum Voltage (kV)
35
Panduit Die Index Number
P45
Finish/Coating
Tin-Plated
Base Material
Copper
Product Name
Terminal Connector
Connector Details
1 x Terminal
Product Material
Copper
Connector Plating
Tin
Product Class
Wire Termination

Description

Lug Compression Connector,2/0 AWG
