  11. One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange LCD3/0-12-X - main

One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange

  • Mfr # LCD3/0-12-X

  • Zoro # G0423051

product price: $15.65
/ea

Key Features

For Wire Size
3/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD3/0-12-X
Zoro #
G0423051
UPC #
7498390094
Country of Origin
Mexico

Dimensions

For Wire Size
3/0 AWG
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
0.96 in
Width
0.96"
Length
4.49"
Cable Size
3/0 AWG
Overall Length
4.49 in
Wire Strip Length (mm)
30.2
Tongue Width (mm)
24.4
Barrel Length (In.)
1.14
Tongue Width (In.)
0.96
Overall Length (In.)
4.49
Copper Code Conductor Size (AWG)
36586
Stud Hole Size (In.)
1 to 2
Tongue Thickness (mm)
3.3
Barrel Length (mm)
29
Overall Length (mm)
114
Stud Hole Size (mm)
12.7
Wire Strip Length (In.)
1.19
Tongue Thickness (In.)
0.13

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Die Code
14
Color Code
Orange
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Panduit Die Index Number
P50
Burndy Die Index Number
14
Base Material
Copper
Stud Hole Spacing (In.)
1.75
Tongue Type
Standard
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (mm)
44.5
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Material
Copper
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Two-hole, standard barrel lug with window, 3/0 AWG wire, 1/2 stud hole, 1.75 hole spacing.
