  11. One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange LCD3/0-38D-X - main

One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange

  • Mfr # LCD3/0-38D-X

  • Zoro # G0415552

product price: $13.64
/ea

Key Features

For Wire Size
3/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.96 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD3/0-38D-X
Zoro #
G0415552
UPC #
7498338329
Country of Origin
Mexico

Dimensions

For Wire Size
3/0 AWG
Barrel Size
Standard
Tongue Width
0.96 in
Width
0.96"
Cable Size
3/0 AWG
Length
3.33"
Overall Length
3.33 in
Wire Strip Length (mm)
30.2
Tongue Width (mm)
24.4
Tongue Width (In.)
0.96
Stud Hole Size (In.)
44993
Overall Length (In.)
3.33
Barrel Length (mm)
29
Overall Length (mm)
84.6
Barrel Length (In.)
1.14
Stud Hole Size (mm)
9.5
Tongue Thickness (mm)
3.3
Copper Code Conductor Size (AWG)
36586
Tongue Thickness (In.)
0.13
Wire Strip Length (In.)
1.19

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
14
Color Code
Orange
Connector Type
Standard Barrel
Features
Corrosion Resistant
Stud Hole Spacing (mm)
25.4
Finish/Coating
Tin-Plated
Burndy Die Index Number
14
Maximum Voltage (kV)
35
Base Material
Copper
Stud Hole Spacing (In.)
1
UL Temperature Rating (°C)
90
Panduit Die Index Number
P50
Product Type
Copper Compression Connectors - Lugs
Tongue Type
Standard
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug,Cu,Sbw,2 Hole,3/0 Awg,3/8
