  11. One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-38F-X - main

One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-38F-X

  • Zoro # G0774057

product price: $18.49
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Standard Barrel
Width
1.19"
Material
Copper
Length
2.07"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-38F-X
Zoro #
G0774057
UPC #
7498343563
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
2.07"
Overall Length
2.07 in
Class K Copper Flex Conductor Size (AWG)
36617
Wire Strip Length (mm)
27
Overall Length (mm)
52.6
Tongue Thickness (mm)
4.1
Class G Copper Flex Conductor Size (AWG)
36617
Stud Hole Size (mm)
9.5
Overall Length (In.)
2.07
Class M Copper Flex Conductor Size (AWG)
36617
Class H Copper Flex Conductor Size (AWG)
36617
Tongue Thickness (In.)
0.16
Tongue Width (mm)
30.2
Class I Copper Flex Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Copper Code Conductor Size (AWG)
36617
Stud Hole Size (In.)
44993
Barrel Length (In.)
1.03
Maximum Copper Conductor Size (AWG)
36617
DLO Copper Flex Conductor Size (AWG)
36617
Barrel Length (mm)
26.2
Wire Strip Length (In.)
1.0625
Tongue Width
1.19 in
Barrel Size
Standard
For Wire Size
4/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Purple
Item
One-Hole Compression Lug
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Die Code
15
Connection Type
1 x Terminal
Connection Material
Tin
Features
90° Angled Connector, Corrosion Resistant
Burndy Die Index Number
15
Base Material
Copper
UL Temperature Rating (°C)
90
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
90 Degrees Angled
T & B Die Index Number
54
Panduit Die Index Number
P54
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Tongue Type
Standard
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
