  11. One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-56F-X - main

One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-56F-X

  • Zoro # G0774039

product price: $17.59
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Standard Barrel
Width
1.19"
Material
Copper
Length
2.07"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-56F-X
Zoro #
G0774039
UPC #
7498343560
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
2.07"
Overall Length
2.07 in
Stud Hole Size (mm)
7.9
Class G Copper Flex Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Wire Strip Length (mm)
27
Wire Strip Length (In.)
1.0625
Tongue Thickness (mm)
4.1
Overall Length (mm)
52.6
Tongue Thickness (In.)
0.16
Class I Copper Flex Conductor Size (AWG)
36617
Stud Hole Size (In.)
45062
Overall Length (In.)
2.07
Class H Copper Flex Conductor Size (AWG)
36617
Barrel Length (mm)
26.2
Barrel Length (In.)
1.03
Class M Copper Flex Conductor Size (AWG)
36617
DLO Copper Flex Conductor Size (AWG)
36617
Copper Code Conductor Size (AWG)
36617
Tongue Width (mm)
30.2
Class K Copper Flex Conductor Size (AWG)
36617
For Wire Size
4/0 AWG
Tongue Width
1.19 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Purple
Item
One-Hole Compression Lug
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Die Code
15
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, 90° Angled Connector
T & B Die Index Number
54
Tongue Type
Standard
Tongue Angle
90 Degrees Angled
Base Material
Copper
Burndy Die Index Number
15
Finish/Coating
Tin-Plated
Panduit Die Index Number
P54
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Connector Details
1 x Terminal
Product Material
Copper
Connector Plating
Tin
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
