  6. One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple LCD4/0-00-X - main

One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCD4/0-00-X

  • Zoro # G0425045

product price:  $19.29
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.06 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCD4/0-00-X
Zoro #
G0425045
UPC #
7498390097
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
Barrel Size
Standard
Tongue Width
1.06 in
Cable Size
4/0 AWG
Length
4.58"
Width
1.06"
Overall Length
4.58 in
Overall Length (In.)
4.58
Overall Length (mm)
116.3
Tongue Width (mm)
26.9
Barrel Length (In.)
1.19
Tongue Thickness (mm)
3.6
Barrel Length (mm)
30.2
Tongue Thickness (In.)
0.14
Tongue Width (In.)
1.06
Wire Strip Length (In.)
1.25
Wire Strip Length (mm)
31.8
Copper Code Conductor Size (AWG)
36617

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Die Code
15
Color Code
Purple
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant
Tongue Type
Standard
Panduit Die Index Number
P54
Burndy Die Index Number
15
Product Type
Compression Connectors - Lugs
Base Material
Copper
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination

Description

Long blank tongue, standard barrel lug, #4/0 AWG wire.
