  11. One-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Standard Barrel, Aluminum, Pink
Panduit One-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Standard Barrel, Aluminum, Pink LAA500-12-2 - main

One-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Standard Barrel, Aluminum, Pink

  • Mfr # LAA500-12-2

  • Zoro # G304859660

product price: $73.99
/ea

Key Features

Material
Aluminum
Color Code
Pink
Hole Center to Center
44563
Barrel Length
3
Tool Type
Aluminum Compression Lugs
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LAA500-12-2
Zoro #
G304859660
UPC #
7498391064
Country of Origin
Mexico

Dimensions

Barrel Length
3
Outside Dia.
1.32
Overall Length
5.5 in
Wire Strip Length (mm)
26.92
Stud Hole Size (In.)
1 to 2
Outer Diameter (In.)
1.32
Stud Hole Size (mm)
12.7
Inside Diameter (In.)
0.84
Tongue Width (mm)
44.19
Tongue Thickness (mm)
11.43
Inside Diameter (mm)
21.33
Aluminum Conductor Size (kcmil)
500
Barrel Length (In.)
3
Wire Strip Length (In.)
3.0625
Overall Length (mm)
139.7
Overall Length (In.)
5.5
Copper Code Conductor Size (kcmil)
500
Tongue Thickness (In.)
0.45
Tongue Width (In.)
1.74
Barrel Length (mm)
76.2
Outer Diameter (mm)
33.52
For Stud Size
1 to 2 in
For Wire Size
500 kcmil
Tongue Width
1.74 in
Barrel Size
Standard

Details

Material
Aluminum
Color Code
Pink
Hole Center to Center
44563
Tool Type
Aluminum Compression Lugs
Standards
cULus. UL/CSA
Item
One-Hole Compression Lug
Burndy Die Index Number
300
CSA Temperature Rating (°C)
90
UL Temperature Rating (°C)
90
Standards Met
cULus. UL/CSA
Finish/Coating
Tin-Plated
Base Material
Aluminum
Tongue Type
Standard
Maximum Voltage (kV)
35
Tongue Angle
Straight
Panduit Die Index Number
P99
Product Type
Aluminum Compression Lugs
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Aluminum

Description

The LAA500-12-2 Aluminum Compression Connector Lug, one-hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
