One-Hole Compression Lug, 6 AWG Max, Long Barrel, Copper, Blue
Mfr # LCCX6-14B-L
Zoro # G504859200
product price: $10.29
/eaKey Features
Material
Copper
Color Code
Blue
Tool Type
Compression Connectors - Lugs
Die Code
7
Overall Length
2.61 in
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
LCCX6-14B-L
Zoro #
G504859200
UPC #
7498342538
Country of Origin
Mexico
Dimensions
Overall Length
2.61 in
Class K Copper Flex Conductor Size (AWG)
6
Stud Hole Size (mm)
6.4
Stud Hole Size (In.)
44930
Wire Strip Length (In.)
1.13
Class I Copper Flex Conductor Size (AWG)
6
Barrel Length (mm)
27.2
Overall Length (mm)
66.3
DLO Copper Flex Conductor Size (AWG)
6
Copper Code Conductor Size (AWG)
6
Class G Copper Flex Conductor Size (AWG)
6
Barrel Length (In.)
1.07
Wire Strip Length (mm)
29
Class M Copper Flex Conductor Size (AWG)
6
Tongue Thickness (In.)
0.08
Overall Length (In.)
2.61
Tongue Width (mm)
12.2
Tongue Width (In.)
0.48
Tongue Thickness (mm)
2
Class H Copper Flex Conductor Size (AWG)
6
For Wire Size
6 AWG
Barrel Size
Long
Tongue Width
0.48 in
Description
Two-hole, flex lug, long barrel, #6 AWG wire, 1/4 stud hole, .75 hole spacing.
