  11. One-Hole Compression Lug, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, Standard Barrel, Copper, Purple LCA4/0-38H-X - main

One-Hole Compression Lug, Standard Barrel, Copper, Purple

  • Mfr # LCA4/0-38H-X

  • Zoro # G804859214

product price: $17.94
/ea

Key Features

Material
Copper
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Hole Center to Center
44628
Tongue Style
Standard
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA4/0-38H-X
Zoro #
G804859214
UPC #
7498355863
Country of Origin
Mexico

Dimensions

Barrel Length
1.19
Tongue Width - Wire Connector
1.06
Overall Length
2.05 in
Wire Strip Length (In.)
1.25
Stud Hole Size (In.)
44993
Barrel Length (mm)
30.2
Tongue Width (mm)
26.9
Overall Length (In.)
2.05
Stud Hole Size (mm)
9.5
Tongue Thickness (mm)
3.6
Tongue Thickness (In.)
0.14
Wire Strip Length (mm)
31.8
Tongue Width (In.)
1.06
Barrel Length (In.)
1.19
Overall Length (mm)
52.1
Copper Code Conductor Size (AWG)
36617
Barrel Size
Standard
Tongue Width
1.06 in

Details

Material
Copper
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Hole Center to Center
44628
Tongue Style
Standard
Item
One-Hole Compression Lug
Tool Type
Tin-Plated Copper Compression Connectors - Lugs
Die Code
15
UL Temperature Rating (°C)
90
Burndy Die Index Number
15
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Panduit Die Index Number
P54
Tongue Type
Standard
Tongue Angle
45 Degrees Angled
Finish/Coating
Tin-Plated
Maximum Voltage (kV)
35
Product Class
Wire Termination
For Conductor Material
Copper

Description

One-hole, standard barrel with window lug, 4/0 AWG sire, 45° angle tongue, 3/8 stud hole.
