Two-Hole Compression Lug, 1 to 2 in Stud, Long Barrel, Copper, Yellow
- Mfr # LCCXN750-12-3
- Zoro # G2754345
product price:Â
$
145.99
/ea
Free Shipping & Returns
Key Features
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
Tongue Width
1.50 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCCXN750-12-3
- Zoro #
- G2754345
- UPC #
- 61305600928
- Country of Origin
- Mexico
- Item
- Two-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- Straight
- Color Code
- Yellow
- Standards
- UL Listed for use in US and Canada to UL 486A-486B for power applications.
- UL Temperature Rating (°C)
- 90
- Product Type
- Compression Connectors - Lugs
- Lug Type
- 2 Stud Hole Lug
- Stud Hole Spacing (In.)
- 1.75
- Panduit Die Index Number
- P115
- Maximum Voltage (kV)
- 35
- Finish/Coating
- Tin-Plated
- Base Material
- Copper
- T & B Die Index Number
- 115
- Burndy Die Index Number
- L115
- Tongue Type
- Narrow
- Stud Hole Spacing (mm)
- 44.45
- Product Class
- Wire Termination
- Number of Holes
- 2
Dimensions
- For Stud Size
- 1 to 2 in
- Barrel Size
- Long
- Tongue Width
- 1.50 in
- Overall Length
- 6.9 in
- Wire Strip Length (mm)
- 77.8
- Tongue Width (In.)
- 1.5
- Overall Length (mm)
- 175.3
- Overall Length (In.)
- 6.9
- Barrel Length (mm)
- 76.2
- Outer Diameter (In.)
- 1.5
- Inside Diameter (mm)
- 29.718
- Tongue Thickness (In.)
- 0.32
- Barrel Length (In.)
- 3
- Stud Hole Size (mm)
- 12.7
- Outer Diameter (mm)
- 38.1
- Inside Diameter (In.)
- 1.17
- Tongue Thickness (mm)
- 8.128
- Tongue Width (mm)
- 38.1
- Stud Hole Size (In.)
- 1 to 2
- Wire Strip Length (In.)
- 3.06
- Outside Diameter Inches
- 1.5 in
