Two-Hole Compression Lug, 1/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Pink
- Mfr # LCCX1/0-12-X
- Zoro # G0776811
product price:Â
$
14.15
/ea
Key Features
For Wire Size
1/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCCX1/0-12-X
- Zoro #
- G0776811
- UPC #
- 7498342577
- Country of Origin
- Mexico
- Item
- Two-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Die Code
- 12
- Color Code
- Pink
- Connector Type
- Long Barrel
- Features
- Corrosion Resistant
- Connection Type
- 1 x Terminal
- Connection Material
- Tin
- Stud Hole Spacing (In.)
- 1.75
- UL Temperature Rating (°C)
- 90
- Product Type
- Compression Connectors - Lugs
- Base Material
- Copper
- Stud Hole Spacing (mm)
- 44.5
- Tongue Type
- Standard
- Panduit Die Index Number
- P42
- Maximum Voltage (kV)
- 35
- Finish/Coating
- Tin-Plated
- Burndy Die Index Number
- 12
- Product Material
- Copper
- Connector Details
- 1 x Terminal
- Connector Plating
- Tin
- Product Name
- Terminal Connector
- Product Class
- Wire Termination
Dimensions
- For Wire Size
- 1/0 AWG
- For Stud Size
- 1 to 2 in
- Barrel Size
- Long
- Tongue Width
- 0.85 in
- Width
- 0.85 in
- Cable Size
- 1/0 AWG
- Length
- 4.83 in
- Overall Length
- 4.83 in
- Tongue Thickness (In.)
- 0.13
- DLO Copper Flex Conductor Size (AWG)
- 36526
- Copper Code Conductor Size (AWG)
- 36526
- Class G Copper Flex Conductor Size (AWG)
- 36526
- Barrel Length (mm)
- 38.1
- Tongue Thickness (mm)
- 3.3
- Tongue Width (mm)
- 21.6
- Overall Length (In.)
- 4.83
- Class M Copper Flex Conductor Size (AWG)
- 36526
- Stud Hole Size (mm)
- 12.7
- Stud Hole Size (In.)
- 1 to 2
- Class K Copper Flex Conductor Size (AWG)
- 36526
- Wire Strip Length (In.)
- 1.56
- Class I Copper Flex Conductor Size (AWG)
- 36526
- Tongue Width (In.)
- 0.85
- Barrel Length (In.)
- 1.5
- Overall Length (mm)
- 122.7
- Wire Strip Length (mm)
- 40
- Class H Copper Flex Conductor Size (AWG)
- 36526
Description
Lug Compression Connector,1/0 AWG
