  11. Two-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink
Panduit Two-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink LCDX1/0-38D-X - main

Two-Hole Compression Lug, 1/0 AWG Max, Standard Barrel, Copper, Pink

  • Mfr # LCDX1/0-38D-X

  • Zoro # G0777730

product price: $11.55
/ea

Key Features

Cable Size
1/0 AWG
Connector Type
Standard Barrel
Width
0.85"
Material
Copper
Length
2.89"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCDX1/0-38D-X
Zoro #
G0777730
UPC #
7498342379
Country of Origin
Mexico

Dimensions

Cable Size
1/0 AWG
Width
0.85"
Length
2.89"
Overall Length
2.89 in
Class H Copper Flex Conductor Size (AWG)
36526
Stud Hole Size (In.)
44993
Wire Strip Length (mm)
19
Class G Copper Flex Conductor Size (AWG)
36526
Class I Copper Flex Conductor Size (AWG)
36526
Overall Length (mm)
73.4
Tongue Width (In.)
0.85
Class K Copper Flex Conductor Size (AWG)
36526
DLO Copper Flex Conductor Size (AWG)
36526
Copper Code Conductor Size (AWG)
36526
Wire Strip Length (In.)
44989
Stud Hole Size (mm)
9.5
Barrel Length (mm)
18.3
Tongue Width (mm)
21.6
Tongue Thickness (In.)
0.13
Class M Copper Flex Conductor Size (AWG)
36526
Overall Length (In.)
2.89
Tongue Thickness (mm)
3.3
Barrel Length (In.)
0.72
Barrel Size
Standard
Tongue Width
0.85 in
For Wire Size
1/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Pink
Item
Two-Hole Compression Lug
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Color
Pink
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Maximum Voltage (kV)
35
Tongue Angle
Straight
Panduit Die Index Number
P42
T & B Die Index Number
42
Stud Hole Spacing (In.)
1
Tongue Type
Standard
Burndy Die Index Number
12
Product Type
Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Base Material
Copper
Stud Hole Spacing (mm)
25.4
Finish/Coating
Tin-Plated
Connector Plating
Tin
Product Material
Copper
Product Name
Terminal Connector
Connector Details
1 x Terminal
Product Color
Pink
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,1/0 AWG
