  11. Two-Hole Compression Lug, 2 AWG Max, Standard Barrel, Copper, Brown
Panduit Two-Hole Compression Lug, 2 AWG Max, Standard Barrel, Copper, Brown LCD2-14A-Q - main

Two-Hole Compression Lug, 2 AWG Max, Standard Barrel, Copper, Brown

  • Mfr # LCD2-14A-Q

  • Zoro # G0777347

product price: $8.39
/ea

Key Features

Cable Size
2 AWG
Connector Type
Standard Barrel
Width
0.6"
Material
Copper
Length
2.4"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD2-14A-Q
Zoro #
G0777347
UPC #
7498338298
Country of Origin
Mexico

Dimensions

Cable Size
2 AWG
Width
0.6"
Length
2.4"
Overall Length
2.4 in
Stud Hole Size (In.)
44930
Tongue Thickness (mm)
2.5
Overall Length (mm)
61
Wire Strip Length (mm)
23.6
Copper Code Conductor Size (AWG)
2
Tongue Width (mm)
15.2
Outer Diameter (mm)
10.66
Overall Length (In.)
2.4
Barrel Length (mm)
22.4
Wire Strip Length (In.)
15/16
Inside Diameter (In.)
0.31
Inside Diameter (mm)
7.87
Outer Diameter (In.)
0.42
Stud Hole Size (mm)
6.4
Tongue Width (In.)
0.6
Barrel Length (In.)
0.88
Tongue Thickness (In.)
0.1
Barrel Size
Standard
For Wire Size
2 AWG
Tongue Width
0.60 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Brown
Item
Two-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
10
Connection Type
1 x Terminal Power
Connection Material
Tin
Tongue Type
Standard
Burndy Die Index Number
10
Base Material
Copper
Panduit Die Index Number
P33
Maximum Voltage (kV)
35
Stud Hole Spacing (In.)
0.63
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Lug Type
2 Stud Hole Lug
Stud Hole Spacing (mm)
16
T & B Die Index Number
10
Finish/Coating
Tin-Plated
Tongue Angle
Straight
Product Name
Power Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal Power
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.2 AWG

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
