  6. Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow
Panduit Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow LCC250-12W-X - main

Two-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow

  • Mfr # LCC250-12W-X

  • Zoro # G0775630

product price:  $23.59
/ea

Key Features

For Wire Size
250 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LCC250-12W-X
Zoro #
G0775630
UPC #
7498379836
Country of Origin
Mexico

Dimensions

For Wire Size
250 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.17 in
Width
1.17"
Cable Size
250 kcmil
Length
5.03"
Overall Length
5.03 in
Overall Length (In.)
5.03
Tongue Thickness (mm)
3.6
Overall Length (mm)
127.8
Tongue Thickness (In.)
0.14
Stud Hole Size (In.)
1 to 2
Outer Diameter (In.)
0.77
Outer Diameter (mm)
19.55
Inside Diameter (mm)
16
Barrel Length (mm)
40.9
Inside Diameter (In.)
0.63
Tongue Width (In.)
1.17
Copper Code Conductor Size (kcmil)
250
Wire Strip Length (In.)
42380
Barrel Length (In.)
1.61
Tongue Width (mm)
29.7
Stud Hole Size (mm)
12.7
Wire Strip Length (mm)
42.9

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
16
Color Code
Yellow
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant
Stud Hole Spacing (In.)
1.75
Finish/Coating
Tin-Plated
T & B Die Index Number
16
Maximum Voltage (kV)
35
Burndy Die Index Number
16
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Stud Hole Spacing (mm)
44.5
Tongue Type
Standard
Lug Type
2 Stud Hole Lug
Base Material
Copper
Panduit Die Index Number
P62
Connector Details
1 x Terminal
Connector Plating
Tin
Product Name
Terminal Connector
Product Material
Copper
Product Class
Wire Termination

Description

Lug Compression Connector,250 Kcmil
