  6. Two-Hole Compression Lug, 4 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Gray
Panduit Two-Hole Compression Lug, 4 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Gray LCC4-12W-L - main

Two-Hole Compression Lug, 4 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Gray

  • Mfr # LCC4-12W-L

  • Zoro # G304859035

product price:  $16.39
/ea

Key Features

For Wire Size
4 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCC4-12W-L
Zoro #
G304859035
UPC #
7498379782
Country of Origin
Mexico

Dimensions

For Wire Size
4 AWG
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
0.75 in
Tongue Width - Wire Connector
0.75
Barrel Length
1.05
Overall Length
4.01 in
Overall Length (mm)
101.9
Tongue Thickness (In.)
0.07
Tongue Width (In.)
0.75
Tongue Thickness (mm)
1.8
Copper Code Conductor Size (AWG)
4
Stud Hole Size (In.)
1 to 2
Wire Strip Length (In.)
1.13
Wire Strip Length (mm)
28.6
Overall Length (In.)
4.01
Tongue Width (mm)
19.1
Barrel Length (mm)
26.7
Stud Hole Size (mm)
12.7
Barrel Length (In.)
1.05

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Die Code
8
Color Code
Gray
Tool Type
Tin-Plated Copper Compression Connectors - Lugs
Hole Center to Center
44563
Tongue Style
Standard
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Base Material
Copper
Panduit Die Index Number
P29
Stud Hole Spacing (In.)
1.75
Stud Hole Spacing (mm)
44.5
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
8
Finish/Coating
Tin-Plated
Tongue Type
Standard
Product Class
Wire Termination

Description

Two-hole, long barrel lug with window, #4 AWG wire, 1/2 stud hole, 1.75 hole spacing.
