Two-Hole Compression Lug, 350 kcmil Max, Long Barrel, Copper, Blue
- Mfr # LCCX350-38D-6
- Zoro # G0424320
product price:Â
$
37.99
/ea
Key Features
For Wire Size
350 kcmil
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
1.54 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCCX350-38D-6
- Zoro #
- G0424320
- UPC #
- 7498342616
- Country of Origin
- Mexico
- Item
- Two-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Die Code
- 19
- Color Code
- Blue
- Connector Type
- Long Barrel
- Connection Type
- 1 x Terminal
- Connection Material
- Tin
- Features
- Corrosion Resistant
- Maximum Voltage (kV)
- 35
- Base Material
- Copper
- Tongue Type
- Standard
- Product Type
- Compression Connectors - Lugs
- Finish/Coating
- Tin-Plated
- Stud Hole Spacing (In.)
- 1
- Burndy Die Index Number
- 19
- Panduit Die Index Number
- P76
- UL Temperature Rating (°C)
- 90
- Stud Hole Spacing (mm)
- 25.4
- Connector Plating
- Tin
- Connector Details
- 1 x Terminal
- Product Material
- Copper
- Product Name
- Terminal Connector
- Product Class
- Wire Termination
Dimensions
- For Wire Size
- 350 kcmil
- Barrel Size
- Long
- Tongue Width
- 1.54 in
- Cable Size
- 350 kcmil
- Width
- 1.54 in
- Length
- 4.95"
- Overall Length
- 4.95 in
- Barrel Length (In.)
- 2.5
- Wire Strip Length (In.)
- 2.56
- Stud Hole Size (mm)
- 9.5
- Tongue Thickness (mm)
- 5.6
- DLO Copper Flex Conductor Size (kcmil)
- 373
- Overall Length (In.)
- 4.95
- Stud Hole Size (In.)
- 44993
- Tongue Thickness (In.)
- 0.22
- Tongue Width (mm)
- 39.1
- Class G Copper Flex Conductor Size (kcmil)
- 350
- Class K Copper Flex Conductor Size (kcmil)
- 350
- Overall Length (mm)
- 125.7
- Class I Copper Flex Conductor Size (kcmil)
- 350
- Class M Copper Flex Conductor Size (kcmil)
- 350
- Wire Strip Length (mm)
- 65
- Class H Copper Flex Conductor Size (kcmil)
- 350
- Barrel Length (mm)
- 63.5
- Tongue Width (In.)
- 1.54
Description
Two-hole, flex lug, long barrel, 350 kcmil cable, 3/8 stud hole, 1 hole spacing.
