  11. Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray
Panduit Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray LCC4-14DW-L - main

Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray

  • Mfr # LCC4-14DW-L

  • Zoro # G0776078

product price: $8.85
/ea

Key Features

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Connector Type
Long Barrel
Width
0.55"
Material
Copper
Length
2.63"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC4-14DW-L
Zoro #
G0776078
UPC #
7498381900
Country of Origin
Mexico

Dimensions

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Width
0.55"
Length
2.63"
Overall Length
2.63 in
Overall Length (In.)
2.63
Copper Code Conductor Size (AWG)
4
Tongue Thickness (mm)
2.3
Wire Strip Length (mm)
28.6
Overall Length (mm)
66.8
Stud Hole Size (mm)
6.4
Stud Hole Size (In.)
44930
Tongue Width (mm)
14
Barrel Length (mm)
26.7
Tongue Thickness (In.)
0.09
Wire Strip Length (In.)
1.13
Barrel Length (In.)
1.05
Tongue Width (In.)
0.55
For Wire Size
4 to 2 AWG
Barrel Size
Long
Tongue Width
0.55 in

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Gray
Item
Two-Hole Compression Lug
Die Code
8
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (mm)
25.4
Stud Hole Spacing (In.)
1
Finish/Coating
Tin-Plated
Burndy Die Index Number
8
Tongue Type
Standard
Panduit Die Index Number
P29
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Base Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Material
Copper
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,4-3 AWG
