  11. Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple
Panduit Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple LCCX4/0-12-X - main

Two-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Purple

  • Mfr # LCCX4/0-12-X

  • Zoro # G0776933

product price: $19.39
/ea

Key Features

Cable Size
4/0 AWG
Connector Type
Long Barrel
Width
1.19"
Material
Copper
Length
5.73"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCCX4/0-12-X
Zoro #
G0776933
UPC #
7498343778
Country of Origin
Mexico

Dimensions

Cable Size
4/0 AWG
Width
1.19"
Length
5.73"
Overall Length
5.73 in
Wire Strip Length (In.)
39452
Outer Diameter (In.)
0.71
Inside Diameter (In.)
0.57
Inside Diameter (mm)
14.47
Tongue Width (mm)
30.2
Wire Strip Length (mm)
41.2
Stud Hole Size (mm)
12.7
Tongue Width (In.)
1.19
Overall Length (mm)
145.5
Overall Length (In.)
5.73
Barrel Length (In.)
2.24
Outer Diameter (mm)
18.03
Tongue Thickness (In.)
0.16
Copper Code Conductor Size (AWG)
36617
Stud Hole Size (In.)
1 to 2
DLO Copper Flex Conductor Size (AWG)
36617
Barrel Length (mm)
56.9
Tongue Thickness (mm)
4.1
Barrel Size
Long
For Stud Size
1 to 2 in
Tongue Width
1.19 in
For Wire Size
4/0 AWG

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Purple
Item
Two-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Hole Center to Center
1.75 in
Die Code
15
Features
Corrosion Resistant
Base Material
Copper
Tongue Angle
Straight
Panduit Die Index Number
P54
Finish/Coating
Tin-Plated
Stud Hole Spacing (mm)
44.5
Tongue Type
Standard
Lug Type
2 Stud Hole Lug
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (In.)
1.75
Maximum Voltage (kV)
35
Burndy Die Index Number
15
T & B Die Index Number
15
UL Temperature Rating (°C)
90
Connector Details
1 x Terminal
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Product Class
Lugs, Splices, Split Bolts & Accessories
Number of Holes
2
For Conductor Material
Copper

Description

Lug Compression Connector,4/0 AWG
