  11. Two-Hole Compression Lug, 450 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown
Panduit Two-Hole Compression Lug, 450 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown LCCX450-12-6 - main

Two-Hole Compression Lug, 450 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown

  • Mfr # LCCX450-12-6

  • Zoro # G0777021

product price: $55.75
/ea

Key Features

Cable Size
450 kcmil
Connector Type
Long Barrel
Width
1.7"
Material
Copper
Length
6.37"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCCX450-12-6
Zoro #
G0777021
UPC #
7498319820
Country of Origin
Mexico

Dimensions

Cable Size
450 kcmil
Width
1.7"
Length
6.37"
Overall Length
6.37 in
Tongue Width (mm)
43.2
Overall Length (mm)
161.8
Wire Strip Length (In.)
38020
Inside Diameter (mm)
23.36
Stud Hole Size (In.)
1 to 2
DLO Copper Flex Conductor Size (kcmil)
444.4
Tongue Thickness (mm)
6.6
Tongue Thickness (In.)
0.26
Stud Hole Size (mm)
12.7
Wire Strip Length (mm)
69.9
Overall Length (In.)
6.37
Tongue Width (In.)
1.7
Inside Diameter (In.)
0.92
Barrel Length (In.)
2.69
Barrel Length (mm)
68.3
Outer Diameter (In.)
1.19
Outer Diameter (mm)
30.22
Outside Diameter Inches
1.19 in
For Wire Size
450 kcmil
Barrel Size
Long
Tongue Width
1.70 in
For Stud Size
1 to 2 in

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Brown
Item
Two-Hole Compression Lug
Die Code
20
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
Lug Type
2 Stud Hole Lug
Panduit Die Index Number
P87
Burndy Die Index Number
20
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
T & B Die Index Number
20
Product Type
Copper Compression Connectors - Lugs
Tongue Angle
Straight
Maximum Voltage (kV)
35
Stud Hole Spacing (mm)
44.5
Stud Hole Spacing (In.)
1.75
Base Material
Copper
Tongue Type
Standard
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination
Number of Holes
2
For Conductor Material
Copper

Description

Lug Compression Connector,450 Kcmil
