Two-Hole Compression Lug, 500 kcmil Max, Standard Barrel, Copper, Pink
Mfr # LCDXN500-38D-6
Zoro # G0778150
product price:Â $55.95
/eaKey Features
For Wire Size
500 kcmil
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.31 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
LCDXN500-38D-6
Zoro #
G0778150
UPC #
7498344273
Country of Origin
Mexico
Dimensions
For Wire Size
500 kcmil
Barrel Size
Standard
Tongue Width
1.31 in
Cable Size
500 kcmil
Length
4.37 in
Width
1.3 in
Overall Length
4.37 in
Barrel Length (mm)
37.6
Class M Copper Flex Conductor Size (kcmil)
500
Tongue Thickness (mm)
7.1
Class I Copper Flex Conductor Size (kcmil)
500
Stud Hole Size (In.)
44993
Tongue Width (mm)
33
Wire Strip Length (mm)
40
Class G Copper Flex Conductor Size (kcmil)
500
Class H Copper Flex Conductor Size (kcmil)
500
Wire Strip Length (In.)
1.56
Overall Length (In.)
4.37
DLO Copper Flex Conductor Size (kcmil)
500
Outer Diameter (In.)
1.3
Tongue Thickness (In.)
0.32
Barrel Length (In.)
1.48
Tongue Width (In.)
1.3
Stud Hole Size (mm)
9.5
Class K Copper Flex Conductor Size (kcmil)
500
Overall Length (mm)
109.7
Description
Lug Compression Connector,500 Kcmil
