90° Elbow, 316 Stainless Steel, 3/8 in x 3/8 in, Male SAE x Female SAE, 5,000 psi
Mfr # 6 AOEG5-SS
Zoro # G300689742
Key Features
Specifications
Product Information
- MFR #
- 6 AOEG5-SS
- Zoro #
- G300689742
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Hex Size
- 7/8 in
- Fitting Side A Nominal Pipe Size
- 3/8 in
- Fitting Side B Nominal Pipe Size
- 3/8 in
Details
- Specific Fitting Shape
- 90 Degrees Elbow
- Pipe Fitting Material
- Stainless Steel
- Item
- Metal Pipe Elbow
- Standards
- ANSI B1.1, FED-STD-H28/2, SAE J1926, SAE J514
- Color
- Silver
- Application
- Oils
- Includes Pre-Applied Thread Sealant
- No
- Fitting Side A Type
- Threaded
- Fitting Side B Gender
- Female
- Maximum Operating Pressure
- 5,000 psi
- Seal Material
- NBR
- Material Grade
- 316
- Fitting Side B Type
- Threaded
- Fitting Side A Gender
- Male
- Includes Seal
- Yes
- Side B Thread Type
- SAE
Description
The PARKER - 6 AOEG5-SS is a 90-degree elbow stainless steel pipe fitting designed to connect two pipes at a right angle, facilitating a change in flow direction. Constructed from 316 stainless steel, it is suitable for use with hydraulic fluid systems and 316 stainless steel provides corrosion resistance; the product is rated for a maximum operating pressure of 5,000 psi. The fitting features SAE-type connections on both sides, with a 3/8 inch nominal pipe size, where Side A is male and Side B is female. It includes a nitrile sealing component. Key Features:
- Material: 316 stainless steel.
- Connection types: SAE on both sides with male gender on Side A and female gender on Side B.
- Nominal pipe size: 3/8 inch on both sides.
- Maximum operating pressure: 5,000 psi.
- Seal: Includes a nitrile sealing component.
- Hex size: 7/8 inch for wrenching.
- Applications: Rated for hydraulic fluid systems.
- Standards compliance: ANSI B1.1, FED-STD-H28/2, SAE J1926, SAE J514.
- Does not include pre-applied thread sealant.
