Shop PARKER

Coupler

  • Mfr # 21KRTF10MPX
  • Zoro # G216423959
product price:
$
15.99
/ea

Key Features

Material
Brass
Coupling Component
Plug
Connection Type
Hose Barb
Hose Fitting Size
3/8 in
Max. Flow Rate
550 lpm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
21KRTF10MPX
Zoro #
G216423959
UPC #
-
Country of Origin
Germany
Item
Quick Connect Air Coupling
Material
Brass
Coupling Component
Plug
Connection Type
Hose Barb
Max. Flow Rate
550 lpm
Seal Material
HNBR
Includes Valve
No
Temp. Range
-4 Degrees to 212 Degrees F
Standards
ATEX, RoHS
For Use With
Gas, Liquids, Pneumatic
Barbed
Yes
Valve Type
Standard
Interchange Type
European Profile
For Hose I.D.
3/8 in
Hose Fitting Gender
Female
Max. Working Pressure @ 70 F
35 bar
Coupling Locking Type
Push-to-Connect
Shell Material
Brass
Compatible Product Type
Gas, Liquids, Pneumatic

Dimensions

Hose Fitting Size
3/8 in
Body Size - Quick Connect Air Couplings
3/16 in
Max. Outside Dia.
5/8 in

Description

The PARKER - 21KRTF10MPX is a brass quick coupler for connection/disconnection without additional tools (tool-free connection/disconnection). It features a hose barb connection type with a 10 mm hose fitting size and a 5 mm body size. The sealing element is made from NBR (nitrile) material, rated for operation within the specified temperature range of -4°F to 212°F.

Key Features:

  • Material: Brass for the main body construction
  • Connection Type: Hose Barb with barbed hose tail
  • Hose Fitting Size: 10 mm
  • Body Size: 5 mm
  • Seal Material: NBR (nitrile)
  • Maximum flow rate: 550 L/min
  • Maximum Outside Diameter: 16 mm
  • Temperature Range: -4°F to 212°F
  • Includes Valve: No (sold without valve)
  • Valve Type: Standard (not included)
  • Compliance Standards: ATEX, RoHS
