Nose Piece Assembly Coupling, Steel Body, Push-to-Connect Lock, 7/8"-14 Thread Size

Mfr # FF-502-10FO
Zoro # G116245040

75.19

Key Features

Body Material

Steel

Seal Material

Buna-N

Coupling Locking Type

Push-to-Connect

Thread Size

7/8"-14

Connection Type

Threaded

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: FF-502-10FO
Zoro #: G116245040
UPC #: -
Country of Origin: United States

Dimensions

Thread Size: 7/8"-14
Coupling Size: 1/2 in
Max. Outside Dia.: 1 9/16 in
Overall Length: 2 15/16 in
Wire Rope Length: 2 15/16 in
Length: 2 15/16 in

Details

Item: Hydraulic Quick Connect Hose Coupling
Body Material: Steel
Seal Material: Buna-N
Coupling Locking Type: Push-to-Connect
Connection Type: Threaded
For Use With: Agricultural Implements, Construction Equipment Attachments, Coolant Fill and Drain Lines, Hydraulic Tools, Industrial Hydraulic Lines
Sleeve Material: Steel
Temp. Range: -40 Degrees to 250 Degrees F
Max. Flow Rate: 45.42 lpm
Includes Valve: No
Finish/Coating: Zinc Nickel Plated
Coupling Component: Plug
Hose Fitting Gender: Female
Includes Shut Off: Yes
Valve Type: Flat Face
Standards: HTMA - ISO 16028
Operating Temperature - Maximum: 250 Degrees F
Max. Working Pressure @ 70 F: 3,000 psi
Operating Temperature - Minimum: -40 Degrees F
Series: FF

Description

Nose Piece Assembly Coupling, Plug, Steel, Coupling Size 1/2 in, Female, Max. Flow Rate 45.425 lpm
