Rotary Plug Valve, 3/8 In, 316 SS, 1/4 Turn

Mfr # 6Z-PR6-VT-SS
Zoro # G1692792

228.99

Free Shipping & Returns

Key Features

Tube Size

3/8"

Connection Type

CPI(R)

Valve Design

2-Way

Body Material

316 Stainless Steel

Max. Pressure

3000 psi CWP

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: 6Z-PR6-VT-SS
Zoro #: G1692792
UPC #: -
Country of Origin: United States

Dimensions

Tube Size: 3/8"
Overall Height: 1 5/32 in
Overall Length: 2.66 in
Connection Size - Side 2: 3/8 in
Connection Size - Side 1: 3/8 in
Nominal Valve Size: 3/8 in
Handle Length: 2.4 in
Wire Rope Length: 2.66 in
Length: 2.66 in

Details

Connection Type: CPI(R)
Valve Design: 2-Way
Body Material: 316 Stainless Steel
Item: Rotary Plug Valve
Max. Pressure: 3000 psi CWP
Coefficient of Volume: 3.19
Seal Material: FKM
Handle Type: Lever
Standards: ASTM
Temp. Range: -10 Degrees To 450 Degrees F
Coefficient of Volume (Cv): 1.24
Plug Material: 316 Stainless Steel
Operating Temperature - Maximum: 300 Degrees F
Connection Type - Side 1: Compression
For Media: Chemicals, Gas, Oil
Connection Type - Side 2: Compression
Maximum Pressure - Operating: 3,000 psi
Operating Temperature - Minimum: -65 Degrees F
Valve Flow Pattern: 2-Way
Valve Series: PR

Description

Rotary Plug Valve, 2-Way, Body Material 316 Stainless Steel, Connection Type CPI(R), Tube Size 3/8 in, Max. Pressure 3000 psi CWP, Temp. Range -10 Degrees To 450 Degrees F, Coefficient of Volume 3.19, Handle Type Lever, Seal Material FKM, Overall Height 1 5/32 in, Overall Length 2.66 in, Standards ASTM

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
