Shop PASS & SEYMOUR

Locking Plug, 30 A, 120/208V AC, Three Phase, 4 Pole, Screw Terminals, Yellow

  • Mfr # 28W09AM

  • Zoro # G814760449

product price:
$
87.79
/ea

Key Features

NEMA Plug Configuration
Non-NEMA
Current Rating
30 A
Phase
Three
Number of Poles
4
Number of Wires
4
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
28W09AM
Zoro #
G814760449
UPC #
785007056112
Country of Origin
United States

Dimensions

Maximum Wire Size
6 AWG
Outside Diameter
1.85 in
Minimum Wire Size
12 AWG
Body Length
2.62 in
Face Diameter
1.85 in
Length
2.62 in
For Maximum Cable Diameter
0.93 in
For Minimum Cable Diameter
0.64 in
Wire Rope Length
2.62 in
Overall Length
2.62 in

Details

Item
Locking Plug
NEMA Plug Configuration
Non-NEMA
Current Rating
30 A
Voltage Rating
120/208V AC
Phase
Three
Number of Poles
4
Number of Wires
4
Number of Blades
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Shrouded
No
Housing Color
Yellow
Standards
CSA Certified, JIS Z2801, NSF Certified, RoHS Compliant, UL Listed
Resistance Properties
Antimicrobial, Moisture Resistant, UV/Sunlight Resistant, Watertight
IP Rating
IP65, IP66, IP67
Grade
General Use
For Environment
Food and Beverage, Sanitary, Clean Room, Institutional
Housing Material
Thermoplastic Elastomer
Midget Locking
No
Minimum Operating Temperature
-40 Degrees F
Blade Material
Nickel-Plated Brass
Features
Anti-Microbial Additive Resistant to Scuffing and Cleaning, Anti-Microbial Additives Embedded in Polymer and Inhibits Growth of Bacteria, Molds, Mildews and Fungi, Keyed Body and Cover for Alignment, Patent Pending, Resistant to High Pressure Hose-Down ApplicationsTongue and Groove Environmental Sealing
Polarized
Yes
Maximum Operating Temperature
140 Degrees F
UL 94 Flammability Rating
V-0
Series
TURNLOK(R)
Power and Ground Indicating Light
No

Description

Locking Plug, Connection Orientation Straight, Current Rating 30 A, Housing Color Yellow, Housing Material Thermoplastic Elastomer, NEMA Plug Configuration Non-NEMA, Number of Blades 3, Number of Poles 4, Phase Three, Polarized Yes, Resistance Properties Antimicrobial, Moisture Resistant, UV/Sunlight Resistant, Voltage Rating 120/208V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Face Diameter 1.85 in, Grade General Use, IP Rating IP65, IP66, IP67, Midget Locking No
