Precion Lead Screw, 0.003 in/ft Lead
Mfr # LSR1601T-0300-RCF-231-NNN-N
Zoro # G309788545
product price:Â
$
329.99
/ea
Free Shipping & Returns
Key Features
Percent Efficiency
19%
Nut Material
Stainless Steel
Nut Length
49.5 mm
Insulation Resistance
100 Mohm
Nut Shape
Round
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- LSR1601T-0300-RCF-231-NNN-N
- Zoro #
- G309788545
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Nut Length
- 49.5 mm
- Screw Diameter
- 16 mm
- Motor Size
- NEMA 23
- Lead Length
- 1 mm
- Nut Mounting Hole Diameter
- 5.6 mm
- Nut Flange Thickness
- 6.4 mm
- Screw Length
- 300 mm
- Nut Bolt Circle Diameter
- 44.5 mm
- Nut Diameter
- 20.3 mm
- Motor Length
- 57.0 mm
- Nut Flange Diameter
- 54 mm
Description
Precision Lead Screw, Nut Type Anti-Backlash, Coating Material PTFE, Screw Material Stainless Steel, Screw Material Grade 300, Frame NEMA 23, Nut Shape Round, Insulation Class B, Screw Diameter 16 mm, Lead Length 1 mm, Screw Length 300 mm, Nut Length 49.5 mm, Nut Flange Diameter 54 mm, Motor Length 57.0 mm, Rated Current 2.2 A, Steps per Revolution 200, Motor IP Rating IP40, Phase 2, Motor Maximum Operating Temperature 50 Degrees C, Motor Minimum Operating Temperature -20 Degrees C
