Shop PEGASUS

Caster, Swivel Plate, White Nylon, 2200 lb.

  • Mfr # P23S-NM080K-16

  • Zoro # G0251122

product price:
$
445.99
/ea
Free Shipping & Returns

Key Features

Wheel Width
2 in
Tread Color
White
Caster Brake Type
No Brake Included
Standards
RoHS, ICWM
Mounting Bolt Dia.
1/2 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
P23S-NM080K-16
Zoro #
G0251122
UPC #
-
Country of Origin
China

Dimensions

Wheel Width
2 in
Mounting Bolt Dia.
1/2 in
Wheel Dia.
8 in
Overall Height
10-1/2 in
Swivel Radius
6 in
Mounting Plate Size
4-1/2 in x 6-1/4 in
Mounting Plate Thickness
0.276 in

Details

Item
Caster,Swivel Plate,White Nylon,2200 lb.
Tread Color
White
Caster Brake Type
No Brake Included
Standards
RoHS, ICWM
Caster Sub-Type
Swivel
Caster Brake Included
No
Frame Finish
Zinc Plated
Non-Marking
Yes
Inside Bolt Hole Spacing
2-7/16 in x 4-15/16 in
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Replacement Wheel
Mfr. No. P-NM-080x020/050K
Number of Wheels
1
System of Measurement
Inch
Core Color
Black
Tread
Standard
Caster Mounting Type
Plate
Application
Retail, Industrial, Commercial, Corrosion Resistance
Extended Lead
No
Caster Frame Material
Forged Steel
Swivel Raceway Type
Double Ball
Wheel Core Material
Nylon
Series
P23 Series
Number of Mounting Holes
4
Tread Shape
Standard
Includes Thread Guards
No
ESD Conductive
No
Resistant To
High Chemical Resistance To Many Aggressive Substances
Load Capacity
2200 lb
Load Rating Range
Heavy Duty
Wheel/Tread Material
Machined Nylon
Wheel Bearing Type
Precision Ball
Wheel Hardness Rating
70-80 Shore D
Operating Temperature Range
-20 Degrees To 250 Degrees F

Description

Caster,Swivel Plate,White Nylon,2200 lb.
