Shop PERLE SYSTEMS

2PORT WL DEVICE SVR RS232 /422/485 DB9M SDS2 W 802.11 A/B/G/N

  • Mfr # 04031674
  • Zoro # G4410624
product price:
$
792.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
30 V DC
Interface Ports
Software selectable EIA232/422/485 on DB9M
Serial Port Speeds
300bps to 230Kbps with customizable baud rate support
Mount Type
Panel-mountable, DIN Rail Mountable, Wall Mountable
Material
Metal
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
04031674
Zoro #
G4410624
UPC #
734660316743
Country of Origin
Canada
Item
Device Server
Input Voltage
30 V DC
Interface Ports
Software selectable EIA232/422/485 on DB9M
Serial Port Speeds
300bps to 230Kbps with customizable baud rate support
Mount Type
Panel-mountable, DIN Rail Mountable, Wall Mountable
Material
Metal
Ethernet Technology
Gigabit Ethernet
Network Band
Dual Band
Minimum Operating Temperature
-40°F (-40°C)
Processor Speed
600 MHz
Serial Port
Yes
Network (RJ-45)
Yes
Maximum Operating Temperature
167°F (75°C)
Network Standard
10/100/1000Base-T
Wireless LAN Standard
IEEE 802.11a/b/g/n/i
Standard Memory
512 MB
Management Port
Yes
UNII Band
Yes
Wireless LAN
Yes
Power Consumption
4.23 W
Ingress Protection (IP) Rating
IP40
Number of Serial Ports
2
Media Type Supported
Twisted Pair
ISM Band
Yes
Input Voltage Range
9 VDC to 30 VDC
Product Line
IOLAN

Description

IOLAN SDG2 W Device Server: Wireless LAN (WiFi) client IEEE 802.11 a, b, g, n @ 2.4Ghz/5Ghz, 2 x DB9M connectors with software selectable RS232/422/485 interface, 10/100/1000 Ethernet, advanced data encryption, user authentication and event management security features included, IPv6, COM port redirector, 15kv ESD, AC power adapter included
