Shop PNEUMADYNE

10-32 (F) UNF Brass Check Valve

  • Mfr # C050401
  • Zoro # G4275153
product price:
$
9.79
/ea

Key Features

Hex Size
5/16 in
Connection Type
UNF
Body Material
Brass with Electroless Nickel
Seat Material - Check Valves
Brass, Electroless Nickel
Sub-Category
Brass
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
C050401
Zoro #
G4275153
UPC #
-
Country of Origin
United States
Connection Type
UNF
Body Material
Brass with Electroless Nickel
Seat Material - Check Valves
Brass, Electroless Nickel
Sub-Category
Brass
Max. Steam Pressure - Valves
Not Rated
Seal Material - Check Valves
Buna-N
Connection Type - Check Valves
FNPT x FNPT
Application - Valves
General Purpose
Body Material - Valves
Brass, Electroless Nickel
Seat Material
Brass, Nickel-Plated Brass
Item
Check Valve
Seal Material
Buna N
Max. Temp.
160 Degrees F
Cracking Pressure - Check Valves
0.100 psi
Flow Design
Single
Max. Pressure
125 psi
Max. Temp. - Valves
160 Degrees F
Cracking Pressure
0.1 psi
Material of Construction
Brass with Electroless Nickel
Mechanism and Body Design
Inline
Item - Check Valves
Check Valve
Flow
9.5 scfm
Seal
Buna N
3-A Standard Compliance
Not Rated
Maximum Pressure - Operating
125 psi
Silent Check
Standard
Vacuum Service Rating
Not Rated
Connection Gender - Side 1
Female
Operating Temperature - Minimum
-20 Degrees F
Maximum Pressure - Steam
Not Rated
Valve Body Style
Inline
Coefficient of Volume (Cv)
0.09
Operating Temperature - Maximum
160 Degrees F
Connection Gender - Side 2
Female
Connection Type - Side 2
NPT
For Media
General Purpose
Connection Type - Side 1
NPT

Description

The PNEUMADYNE C050401 is an inline check valve designed for general-purpose flow control. It is configured for one-direction flow and reverse-flow control in compatible fluid or gas systems. This valve features a brass body with electroless nickel, a single-flow design, and female NPT connections on both ends.

Key Features:

  • Valve type: Check valve with inline body design
  • Application: General purpose flow control
  • Body material: Brass with electroless nickel
  • Connection type: FNPT x FNPT
  • Connection size: 3/16 in on both sides
  • Nominal valve size / pipe or tube size: 5/16 in
  • Cracking pressure: 0.1 psi
  • Flow capacity: Cv 0.09
  • Flow rate: 9.5 scfm
  • Seal material: Buna-N
  • Seat material: Brass with electroless nickel
  • Maximum operating pressure: 125 psi
  • Operating temperature range: -20 degrees F to 160 degrees F
  • Hex size: 5/16 in
  • Overall length: 0.83 in
  • Overall height: 13/16 in
