Multitap Connector, Aluminum, Gray, Hex, 2 Port

  • Mfr # ITG-1B

  • Zoro # G602716399

product price:  $25.99
/ea

Key Features

Connector Type
Single-Sided Entry
For Wire Size
2 AWG
Number of Ports
2
For Conductor Material
Copper
Body Material
Aluminum
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ITG-1B
Zoro #
G602716399
UPC #
662381959461
Country of Origin
United States

Dimensions

For Wire Size
2 AWG
Hex Size
3/16 in
Length
1.6 in
Width
1.6 in
Wire Size
(Class B,C,D) 1-10 AWG - (Class K,M,I) 2-10 AWG
Stud Size
3/16 in
Max. Conductor Size
1 AWG; 2 AWG
Min. Conductor Size
10 AWG
For Stranded Copper Wire Size - Maximum
2 AWG
Overall Width
1.55 in
Overall Length
1.6 in
For Stranded Copper Wire Size - Minimum
10 AWG
Dimensions
L=1.600 - W=1.550 - H=1.750
Hex Wrench Size
3/16
Conductor Cu Size Range
1-10 AWG (CLASS B, C,D) & 2-10 AWG (Classes G, H, I, K, M, DLO)

Details

Item
Multitap Connector
Connector Type
Single-Sided Entry
Number of Ports
2
For Conductor Material
Copper
Body Material
Aluminum
Insulation Material
Plastisol
Direct Burial Rated
No
Head Style
Hex
Finish
Plastisol
Color
Black
Maximum Operating Temperature
194 Degrees F
Standards
cULus
Type
Multi Cable
Max. Voltage
600 V
No. of Ports
2
Material
Plastisol
Screw Material
Aluminum
RoHS Compliant
Yes
Maximum Voltage
600 V
Environmental Conditions
90 C
Number Of Conductors
2
Application
Wire Termination
Standard
cULus
Wire Type
B,C,D,K,M,I
Temperature Rating
90° C
Voltage Rating
600 V
Env Temp
Cold Temperature rated to -45C
Ul Standard
UL 486A/B
Wire Cable Class
Class B, Class C, Class D, Class G, Class H, Class I, Class K, Class M, Class DLO
Temp Rating
90C, 9CU
Conductors Count
2
Cu Conductor Max Amp
150
Assortment
Fine Stranded Wire Pre-Insulated Connectors
Max Torque
150
Ul File No
E186991

Description

Multitap Connector, Body Material Aluminum, Color Black, Finish Plastisol, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 10 AWG, For Stranded Copper Wire Size - Maximum 2 AWG, Head Style Hex, Hex Size 3/16 in, Insulation Material Plastisol, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Ports 2, UL 94 Flammability Rating Not Applicable, RoHS Compliant Yes, Standards cULus, Connector Type Single-Sided Entry, Direct Burial Rated No
