Polaris Multi-Tap Connector, 4 Port
Mfr # IPLD500-10C
Zoro # G5805407
product price: $266.99
/ea
Free Shipping & Returns
Key Features
Connector Type
Double-Sided Entry
For Wire Size
500 kcmil
Number of Ports
10
For Conductor Material
Aluminum, Copper
Body Material
Aluminum
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
IPLD500-10C
Zoro #
G5805407
UPC #
662381996879
Country of Origin
United States
Dimensions
For Wire Size
500 kcmil
Hex Size
5/16 in
Min. Single Wire Size
4 AWG
Width
2.83 in
Overall Length
12.11 in
Length
12.11 in
Max. Single Wire Size
500 kcmil
Stud Size
5/16 in
Min. Conductor Size
4 AWG
Max. Conductor Size
500 kcmil
Length (Straight Wireway)
12.11 in
Overall Width
2.83 in
For Stranded Copper Wire Size - Maximum
500 kcmil
For Stranded Copper Wire Size - Minimum
4 AWG
Strip Length
1 3/4 in
Conductor Al Size Range
500 MCM-4 AWG
Conductor Cu Size Range
500 MCM-4 AWG
Hex Wrench Size
5/16
Minimum Single Wire Size
4 AWG
Maximum Run Wire Size
500 kcmil
For Minimum Wire Size - Stranded
4 AWG
Maximum Wire Size
500 kcmil
For Minimum Wire Size - Solid
4 AWG
Maximum Single Wire Size
500 kcmil
Minimum Run Wire Size
4 AWG
Minimum Wire Size
4 AWG
Description
Multitap Connector, Body Material Aluminum, Color Clear, Finish Plastisol, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 4 AWG, For Stranded Copper Wire Size - Maximum 500 kcmil, Head Style Hex, Hex Size 5/16 in, Insulation Material Plastisol, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Ports 10, UL 94 Flammability Rating Not Applicable, RoHS Compliant Yes, Standards cULus, UL 486A, UL 486B
