  9. Double Binding Posts, 30VAC/60VDC, Black
Shop All Test Leads & Probes
Pomona Electronics

Double Binding Posts, 30VAC/60VDC, Black

product price: $11.39
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Color Black
  • Length 1.78"
  • Max Amps 15A
  • Application Electronics
  • Includes Mounting Base
See all product information

Product Information

Dimensions

Length 1.78"
Manufacturers Warranty Length 90 day
Contact Diameter 5/32 in

Details

Item Binding Post with Double Mounting
Color Black
Max Amps 15A
Application Electronics
Includes Mounting Base
Temperature Range 239 Degrees F
Features Accepts Standard Banana Plugs, Mounts in Panels from 1.57"to 6.35" Thick, 8-32 Thread, 0.1" Hole Diameter
Hands Free Voltage 2500V AC
Hand Held Voltage 30V AC/60V DC
Body Material Brass
Contact Finish - Test Lead Connector Tin Plated
Body Material - Test Lead Connector Polycarbonate
Contact Material Brass
Item - Test Lead Connector Double Binding Post
Operating Temp. Up to 239 Degrees F
Insulating Material Polycarbonate
Color - Test Lead Connector Black
Max. Amps 15
Insulating Material - Test Lead Connector Polycarbonate
Contact Finish Tin Plated
Max. Amps - Test Lead Connector 15
Contact Material - Test Lead Connector Brass
Standards CE
Maximum Current 15 A
Maximum Voltage 2,500 V
Insulation Material Polycarbonate
Contact Spacing 3/4 in
Maximum Operating Temperature 239 Degrees F

Description

Double Binding Post, Contact Finish Tin Plated, Contact Material Brass, Maximum Current 15 A, Color Black, Body Material Brass, Maximum Voltage 2,500 V, Length 1 3/4 in, Application Electronics, Contact Spacing 3/4 in, Features Accepts Standard Banana Plugs, Mounts in Panels from 1.57 mm (0.062 in) to 6.35 mm (0.25 in) Thick, Contact Diameter 5/32 in, Maximum Operating Temperature 239 Degrees F, Includes Mounting Base, Standards CE, Maximum Temperature Measurement Not Applicable
