  13. Socket, General Purpose Relay, 10 A, Quick Connect, Solder
This item is Discontinued.
Potter-Brumfield Socket, General Purpose Relay, 10 A, Quick Connect, Solder KUL-11D15S-12

Socket, General Purpose Relay, 10 A, Quick Connect, Solder (Discontinued)

  • Mfr # KUL-11D15S-12
  • Zoro # G900947648
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
KUL-11D15S-12
Zoro #
G900947648
UPC #
-
Country of Origin
Mexico

Dimensions

Length
38.9 mm [ 1.55 in ]
Width
35.7 mm [ 1.405 in ]
Height
54.8 mm [ 2.157 in ]

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Quick Connect, Solder
Coil Voltage
12V DC
Current Rating
10 A
Contact Material
AgCdO
Contact Arrangement
2 Form C (CO)
Contact Voltage Rating
240 VAC [ 28 VDC ]
Contact Limiting Making Current (A)
10
Relay Type
KUL Series Panel Relay
Insulation Initial Resistance (MΩ)
100000
Contact Limiting Short-Time Current (A)
10
Coil Power Rating (DC) (mW)
1200
Insulation Initial Dielectric Between Contacts and Coil (Vrms)
1500
Coil Magnetic System
Bistable, 1 Coil
Insulation Initial Dielectric Between Adjacent Contacts (Vrms)
1500
Insulation Initial Dielectric Between Open Contacts (Vrms)
1500
Contact Number of Poles
2
Coil Special Features
Magnetic Latching
Coil Resistance (Ω)
120
Contact Current Class
5 to 10 A, Less Than 16A
Contact Limiting Continuous Current (A)
10
Environmental Ambient Temperature (Max)
70 °C [ 158 °F ]
Contact Limiting Breaking Current (A)
10
Insulation Initial Dielectric Between Coil/Contact Class
1000 V to 1500 VA
Contact Current Rating (A)
10
Environmental Category of Protection
RTI
Environmental Ambient Temperature Class
50 to 70°C
Contact Switching Load (Min)
300mA @ 12V
