Emergency Stop Push Button, 30 mm, 1NO/2NC, Red

  • Mfr # 40102-212
  • Zoro # G9999385

product price:
$
436.99
/ea
Free Shipping & Returns

Key Features

Push Button Style
Mushroom Head
Action
Maintained
Maintained Action Release
Push/Pull
Operator Illumination
Non-Illuminated
Panel Cutout Diameter
30 mm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
40102-212
Zoro #
G9999385
UPC #
-
Country of Origin
Mexico
Item
Emergency Stop Push Button
Push Button Style
Mushroom Head
Action
Maintained
Maintained Action Release
Push/Pull
Operator Illumination
Non-Illuminated
Head Color
Red
Head Material
Plastic
Terminal Connection
Screw Clamp
Standards
ANSI B11.1, IEC 60947-5-5-3.9, OSHA, UL/NISD E357870
NEMA Rating
12, 13
Contact Form
1NO/2NC
Material
metal
Contact Rating
10A @ 600V AC
Basic Material
Metal
Bezel
Die Cast Zinc
Type of Operator
31mm Mushroom Head
Color
Red
IP Rating
IP65
Number of Operators
1
Bezel Material
Zinc Die Cast
Features
Gold Plated Contacts, Positive Break, Sliding Padlock Attachment
DC Contact Rating
2.2 A @ 125V
AC Contact Rating
10 A @ 600 V
Product Type
Emergency Stop Push Buttons
Number of Indicator Lights
0
Operator Voltage Rating - Maximum
600 V AC
Mechanical Operating Durability
1.00 x 10^6
NEMA Enclosure Rating
12, 13
Operating Temperature - Maximum
131 Degrees F
Resistance Properties
Impact Resistant, Oil and Grease Resistant
Operating Temperature - Minimum
32 Degrees F
Operator Material
Plastic

Dimensions

Panel Cutout Diameter
30 mm
Mushroom Head Diameter
50.8 mm
Size
30 mm
Overall Height
6.05 in
Manufacturer Warranty Length
1 yr
Fits Chest Size
Gold Plated Contacts, Positive Break, Sliding Padlock Attachment

Description

Emergency Stop Push Button, 30 mm, Maintained Action, 31mm Mushroom Head Type of Operator, Head Material Plastic, Contact Form 1NO/2NC, Bezel Die Cast Zinc, Color Red, Contact Rating 10A @ 600V AC, Number of Operators 1, NEMA Rating 12, 13, IP Rating IP65, Legend Not Applicable, Standards ANSI B11.1, IEC 60947-5-5-3.9, OSHA, UL/NISD E357870, Terminal Connection Screw Clamp, Features Gold Plated Contacts, Positive Break, Sliding Padlock Attachment, Material Metal
