  6. Cordset, Etherlink RJ45, Male, 6.6 ft.

This item is Discontinued.

Remke Cordset, Etherlink RJ45, Male, 6.6 ft. ERJ04M0066BA5

Cordset, Etherlink RJ45, Male, 6.6 ft. (Discontinued)

  • Mfr # ERJ04M0066BA5
  • Zoro # G7220110
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ERJ04M0066BA5
Zoro #
G7220110
UPC #
785411041450
Country of Origin
United States

Dimensions

Cable Length
6.6 ft.
Wire Size
24 AWG
Height (in)
1.26
Length (in)
1.25
Cable Length (ft)
6.6
Width (in)
0.57
Cable Jacket Outer Diameter (in)
0.32

Details

Item
Etherlink Connector, Plug Assembly
Jacket Color
Black
IP Rating
IP67
Temp. Range
-4 Degrees to 221 Degrees F
Features
Single and Double Ended Options Including an RJ45 Cable Assembly; Available in Male and Female; Straight and 90 Degree Configurations; Receptacles Designed for Conventional Threaded Connections to Ensure Reliable Mating
NEMA Rating
6P
Max. Amps
4A
Color
White/Orange, White/Green, Orange, Green
For Use With
Industrial Ethernet Systems; Sensor Connectors; Actuators; Panels And Cabinets; Automation Components
Body Material
PVC
Max. Voltage
125VAC/VDC
Number of Conductors
4
Wiring Color Code
Ethernet
Poles
4
O-Ring Material
Nitrile Rubber
Conductor Color 1
White/Orange
Coupling Nut Plating
Black Anodized
cRU Specification
E165657
Cable Code
Euro
Contact Resistance (Micro Ohms)
5
Voltage Rating (DC)
125
Contact Material
Brass, Gold Plated Over Nickel"
Minimum Operating Temperature (F)
-4
Wire Gauge
24 AWG
Coupling Nut Material
Aluminum
Maximum Operating Temperature (F)
221
Cordset Configuration
90 Degree
Thread 1
M12X1
Current Rating (amps)
4
Cable Jacket Color
Black
Connector Style
MicroLink Ethernet
Conductor Color 4
Green
Insert Material
Nylon
Cable Jacket Material
TPE
Voltage Rating (AC)
125
Contact Carrier Material
Nylon
Conductor Color 3
Orange
Conductor Color 2
White/Green

Description

Cordset,Etherlink RJ45,Male,6.6 ft.
