Shop All Ignition Systems and Components
Robertshaw

Pilot Ignitor System

product price: $231.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Includes 720-070 Valve, 780-845 Module, LP Regulator, Mounting Harness, Spark/Sensor Probe, Wiring Harness
  • Voltage 24
  • Control Volts 24 V
  • Amps AC 1.5 A
  • Operation Description Convert Conventional Standing Pilot Systems To Intermittent Pilot Systems
See all product information

Product Information

Details

Includes 720-070 Valve, 780-845 Module, LP Regulator, Mounting Harness, Spark/Sensor Probe, Wiring Harness
Voltage 24
Control Volts 24 V
Amps AC 1.5 A
Operation Description Convert Conventional Standing Pilot Systems To Intermittent Pilot Systems
Type Gas Ignition System Kit
Inlet/Outlet (In.) 1/2 x 3/4
For Use With Residential, Commercial Heating Equipment
Gas Type LP/NG
Item Heating Kit
Pressure Setting Range (In. WC) 3.5 Nat./ 11 LP
Method of Opening Slow Opening
BtuH Capacity 200,000 / 320,000
Product Type Heating Kit
Compatible with Series Universal
Minimum Operating Temperature -40 Degrees F
Maximum Capacity 150,000 BtuH
Thermostat Anticipator Setting Thermostat Anticipator
Lock Out Time 90 sec
For Fuel Type LP, Natural Gas
Flame Sensor Current Output 0.7 mA
Pre-Purge Time 6 min
Control Voltage 24V AC
Ignition Cycle Time 90 seconds
Number of Retries 3
OEM Replacement Part Number 21D185, 4E397, 63013, 63014, 661616, 700-002, 700-007, 700-022, 700-027, 700022, 700027, 710-002, 710-007, 711002, 711007, 712-007, 712007, 9998-363, L36-987, L36987, L38-185, L38185, Q15GAA-1, Q15GAA1, VLV49A-602R, VLV49A-604R, VLV49A-605R, VLV49A-606R, VLV49A602R, VLV49A604R, VLV49A605R, VLV49A606R, Y8610H4010, Y86G1002, Y86G1036
Automatic Reset Time 1 hr
Maximum Operating Temperature 175 Degrees F
Series 712
Input Voltage 24V AC
Compatible with Brand Honeywell, Johnson Controls, Johnstone Supply, Uni-Line, White-Rodgers
Main Valve Current Output 1 A

Description

Heating Kit, Product Type Heating Kit, Maximum Operating Temperature 175 Degrees F, Minimum Operating Temperature -40 Degrees F, Lock Out Time 90 sec, Pre-Purge Time 6 min, Number of Retries 3, Main Valve Current Output 1 A, Flame Sensor Current Output 0.7 mA, Ignition Cycle Time 90 seconds, Automatic Reset Time 1 hr, Compatible with Series Universal, Compatible with Brand Honeywell, Johnson Controls, Johnstone Supply, Uni-Line, White-Rodgers
